Designed and Developed in Collaboration with Skudai UTM Team

Features
- Long life MOS sensor
- Propane gas detection
- 5-85% LEL detection
- 5 seconds start-up time
- 24 hours pre-heat time (immediate used is allowed)
- LED power supply/alarm indicator
- 2.5W Maximum power consumption
- NC dry relay
- Optional factory calibrated humidity ranges (0-30%, 31-70%, 71-95%)
- Field-adjustable calibration via trimpot
- 12-28V d.c. wide input voltage supply

SPECIALISE IN:

Energy Savings System, Mechanical & Electrical Engineering, Control Switch Board / DB/ SubDB and MSB, Power Electrical & Control Wiring Works.

ENER-SAVE SDN BHD

30 & 30A, Jalan Perlaluan Besi 3, Taman Sri Putri, 81300 Skudai, Johor, Malaysia.

Tel: +607-557 2669,

Fax: +607-558 2669

E-Mail: sales@ener-save.biz
